Black White PG2357C&2387C Compatible Hikvision NVR Poe Security Camera System
HIKVISION DS-7816NXI-I2/16P/S NVR
H.265+/H.265/H.264+/H.264 video formats
Intelligent analytics based on deep learning algorithm
Up to 4-ch perimeter protection
Up to 1-ch facial recognition for video stream
Up to 4-ch facial recognition for face picture
Up to 16-ch IP camera inputs
Up to 16-ch 1080p decoding capability
PG2357C PG2387C Full color night poe security camera system with upgrade h.265 encoding technology, camera has efficient video encoding capacity, which saves bandwidth and storage space. The camera delivers 8mp resolution at 20fps. The camera is equipped with smooth control, high quality image, and good protection, meeting compactsize demands of video surveillance applications.
Compatible for Hikvision and ON-VIF protocol
The network camera compatible with Hikvision's private connection protocol, it can be plug and play with Hikvision's network video recorder，perfect connection. The camera conformsto the ON-VIF (Open Network Video Interface Forum)specifications, ensuring interoperability between network video products regardless
This series of pixel cameras can be used with Hikvision NVR models at will.
3DNR digital noise reduction
3DNR digital noise reduction technology, reduce the noise that appears when the camera is recording at night, and provide a clearer image.
Protection (IP67, wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes.
4K UltraHD Resolution
Using the latest CMOS image sensor and chipset, the camera has a 103° ultra-wide field of view, a 4k ultra-high-definition picture, and a 24-hour full-color camera, which can record clear color images even at night, providing a smooth and clear visual experience.
High Efficiency Video Coding (H.265)
The H.265 (ITU-T VCEG) video compression standard offers double the data compression ratio at the same level of video quality, or substantially improved video quality at the same bit rate, as compared to older video compression technologies.
|
del
|
PG2357C/PG2387C IP Camera
|
|
1. Camera
|
|
|
Image Sensor
|
2MP: 1/2.7” Sony Sensor
|
|
5MP: 1/2.8" Sony Sensor
|
|
|
8MP: 1/2.8" Sony Sensor
|
|
|
Min. Illumination
|
24/7 full time color
|
|
White Balance
|
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
|
|
Gain
|
Auto/Manual
|
|
Shutter Time
|
50Hz: 1/25 s to 1/100,000 s
|
|
Day & Night
|
N
|
|
Privacy Mask
|
4 programmable privacy masks
|
|
2. Lens
|
|
|
Focal Length
|
F1.0 3.6mm (6mm Optional)
|
|
Field of View |
Horizontal field of view: 103°
Vertical field of view: 69° Diagonal field of view: 110° |
|
3. Compression Standard
|
|
|
Video Compression
|
Main Stream: H.265/H.264
Sub-stream: H.265/H.264 |
|
H.264 Type
|
Baseline profile/Main profile/High profile
|
|
4. Event
|
|
|
Basic Event
|
Motion Detection
|
|
5. LED
|
|
|
White Light Range
|
Warm white LEDs, up to 30m
|
|
White Light
|
4 pieces
|
|
6. Image
|
|
|
Max. Resolution |
2MP: 1920 × 1080
|
|
5MP: 2592 × 1944
|
|
|
8MP: 3840 x 2160
|
|
|
Main Stream
|
2MP: 25fps 2MP(1920x1080)/720P
|
|
5MP: 15fps 5MP(2592 × 1944),20fps 4MP(2560x1440)25fps 3MP/2MP/720P
|
|
|
8MP: 20fps 8MP(3840 x 2160,25fps 6MP(3072x2048)30fps 5MP/4MP/3MP/2MP/720P
|
|
|
Sub-Stream
|
2MP: D1/VGA/640x360/CIF 30fps, etc
|
|
5MP: D1/VGA/640x360/CIF 25fps, etc
|
|
|
8MP: VGA/640x360/480X360P/CIF 25fps, etc
|
|
|
Image Enhancement
|
3D DNR, EIS, Regional Exposure, Privacy Mask, Mirror
|
|
7. Network
|
|
|
Ethernet
|
RJ-45 (10/100Base-T)
|
|
Protocols
|
IPv4/IPv6, HTTP/RTSP/DHCP/NTP/TCP/IP,etc.
|
|
API
|
ONVIF (Profile S, Profile G, Profile T),HIKVISION
|
|
Simultaneous Live View
|
Up to 20 channels
|
|
Client
|
SADP, Danale, Blue Iris, ISpy
|
|
Web Browser
|
IE 8 to 11,Chrome 31.0+, Firefox 30.0+, Edge 16.16299+
|
|
8. Interface
|
|
|
Network Interface
|
1 RJ45 10 M/100 M Ethernet, PoE
|
|
Power
|
12V DC / PoE
|
|
9. General
|
|
|
Language (Web Browser Access )
|
7 languages: Chinese, English, Russian, German, Italian, Turkish, 한국어
|
|
Power |
12 VDC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR)
|
|
PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR)
|
|
|
Working Environment
|
Temperature: -20°C to 60°C (-4°F to 140°F), humidity: ≤ 90%
|
|
Protection Level
|
IP66 standard
|
|
Material
|
Aluminum Alloy
|
|
Dimension
|
Φ 220mm × 100mm x 100mm(Φ 8.66" × 3.94" x 3.94'')
|
|
Weight
|
Approx. 0.8 kg (1.17 lb.)
|
- DS-7816NXI-I2/16P/S NVR
- Facial Recognition
- Face Picture LibraryUp to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)
- Face Picture Comparison4-ch face picture comparison alarm
- Facial Detection And AnalyticsFace picture comparison, human face capture, face picture search
- Facial Detection And Analytics Performance1-ch human face capture (HD network camera, up to 8 MP , H.264/H.265)
- Perimeter Protection
- Human/Vehicle AnalysisUp to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
- Video And Audio
- IP Video Input16
- Incoming Bandwidth320 Mbps
- Outgoing Bandwidth256 Mbps
- HDMI 1 OutputHDMI1 output: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output HDMI2 output:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI2/VGA independent output
- VGA 1 Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
- CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Decoding
- Decoding FormatH.265,H.265+,H.264,H.264+,MPEG4
- Recording Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Playback ModeNormal/Smart, Event, Tag, Eternal File
- Synchronous Playback16-ch
- Live View Window Division1/4/6/8/9/16
- Aux Port Window Division1/4/6/8/9/16
- Decoding Capability16-ch @ 1080p (30 fps)
- Audio CompressionG.711ulaw,G.711alaw,G.722,G.726,MP2L2
- Network
- Network Interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- PoE
- Interface16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Power≤ 200W
- StandardIEEE 802.3 af/at
- Auxiliary Interface
- SATA2 SATA interfaces
- CapacityUp to 8 TB capacity for each disk
- Serial InterfaceRS-485 (half-duplex), RS-232, Keyboard
- Alarm In/Out4/1
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- ESATA1 eSATA interface
- General
- Power Supply≤ 280 W
- Consumption≤ 15W
- Working Temperature-10℃～＋55℃
- Working Humidity10％～90％
- Chassis1U
- Dimension (W × D × H)385 × 315 ×52 mm ( 11.6"× 9.5" × 1.6")
- ≤ 3 kg (6.6 lb)
1.How can we confirm the products are genuine HV and DH English version?
HV and DH softwares can be downloaded from their official website, and only original products are fully compatible with the softwares.
2.Can you provide OEM service? Is there MOQ?
OEM is preferred, no MOQ is required. We support OEM&ODM and customize your logo
3、What payment method can your company provide ?
We accept Amazon Pay, via TT (Bank transfer), Credit Cards, Telegraphic Transfer,Paypal and so on.
4.How is your after-sales service?
Most of our sales engineers and technicians have won HV HCSA certificate. And thanks to manufacturers’ support, all issues can be solved timely and properly.
5. Can I install the IP camera by myself?
Of course,the camera is flexible installated.And there is a user manual within box,you can contact us in need.
6.Do you provide drop shipping service?
We will provide as many shipping options as possible, including DHL, UPS, TNT, FedEx and EMS, Airfreight and by Sea, and we also have third-party warehouse in US and AU, timely shipment can be arranged.
Any more information, please contact us via sales@cctv-outlet.com . we will provide more product information to you, Hope we will server to you. Thanks your support.
